PARKER DC SERVOMOTOR Series
RX

Parker Hannifin

- Motor type: Ferrite magnet DC motors
- Size: 58mm | 84mm | 100mm | 120mm
- Torque range: 0.28 ... 7.8 Nm
- Speed range: 2400 ... 3000 min-1
- Rated voltage: 44.5 ... 134VDC
- Number of poles: 4
- Protection rating: IP40 (RX1-RX3) | IP54 (RX5-RX6)
- Sensor : Tachometer | Encoder
- Marking: CE

- Tree
- RX1 and RX3: Smooth solid shaft
- RX5 and RX6: Keyed solid shaft
- 2nd tree stump
- RX1 and RX3: tacho or encoder can be fitted as standard
- RX5 and RX6: can be fitted with a tacho as standard or adapted for encoder mounting as an option
- Cable outlet 1 m without connector
- Options
- Brake / - Tachometer
- 2nd shaft extension for encoder mounting (RX5 and RX6)

- Excellent price/performance ratio
- Very low torque modulation
- High design quality
- Very long service life
- 2nd shaft end for tacho and encoder mounting
- Tacho and brake option

- Automation
- Life Sciences

Documentation française

Documentation française

English documentation

The Parker RX DC servomotor, combined with RTS drives, offers a cost-effective solution for a wide range of applications. They are particularly suitable for low-power systems in clean environments. The RX DC servomotor provides low torque oscillation and long service life. With torque up to 7.8Nm and 3000rpm, optional tachometer and brake, as well as a second shaft extension.
